C245 Bevel Soldering Tips
Replaceable C245 standard soldering cartridges for T245 soldering handles. The heater is built into the cartridge, so the tip is replaced without disassembling the handle.
The flat bevelled face gives a wide contact area with the board and solder. This shape is suited to heavy joints: ground planes, shields, power connectors, thick wires, and to tinning.
Sizes in the Series
- C2.2, C3 — SMD components, leads, small ground areas.
- C3.5, C3.8 — most board-level work.
- C5, C8.8 — large high-thermal-mass areas, shields, power connectors.
Specifications
| Cartridge standard | C245 |
|---|---|
| Tip shape | Bevel |
| Bevel sizes, mm | 2.2 / 3 / 3.5 / 3.8 / 5 / 8.8 |
| Heater | Built into the cartridge |
| Tip core | Copper |
| Plating | Multi-layer electroplating with a nickel layer |
| Shell | 304 stainless steel |
| Working surface | Pre-tinned |
| Tip replacement | Plugs into the handle, no tools needed |
| Compatibility | T245 standard soldering handles |
| Not compatible | T210 handles (C210 cartridges) |
| Packaging | Individual plastic tube |
Compatibility
T245 standard soldering handles. Not compatible with T210 handles (C210 cartridges).
Package Contents
One tip of the selected size in an individual plastic tube.
